TSC T6304e

Enterprise 4" industrial printer, 300 dpi, PGL/VGL/ZGL emulation, RFID version available

  • Print technologyDirect thermal, Thermal transfer
  • Print width4"
  • Resolution300 dpi
Model
T6304e
Brand
TSC

The TSC T6304e is an enterprise industrial printer with a 104 mm print width and 300 dpi, a die-cast aluminum frame and PGL, VGL, ZGL emulation. A separate RFID version exists; USB, Ethernet, Wi-Fi.

On order

Delivered within one week of payment.

from 35 350 MDL Price incl. VAT

The price is set individually: send a request and we will prepare a quote.

Request a quote Call

BrochuresSpec sheet (EN) EN

Description

At a glance

The TSC T6304e is an industrial printer from the T6e series, with a die-cast aluminum frame and a metal door, for fast-paced environments. It is used in automotive, manufacturing and healthcare, and for product and shipping labels. PGL, VGL and ZGL emulation makes it easier to replace an older printer without rewriting applications. At 300 dpi it prints finer text and codes than the T6204e, at a somewhat lower speed.

Key points

  • 104 mm (4") print width, 300 dpi, speed up to 305 mm/s
  • 450 m ribbon, up to 114.3 mm wide; roll or fan-fold labels, tags, paper, film and tickets
  • PGL, VGL, ZGL emulation and other major printer languages
  • USB, Ethernet, Wi-Fi, RS-232 and parallel; colour LCD with buttons
  • Optional heavy-duty cutter, peeler and rewinder; separate RFID version (T6304e RFID) and ODV-2D barcode verification

Specifications

Printing

Print technologyDirect thermal, Thermal transfer
Print width4"
Print width, mm104 mm (4.09")
Resolution300 dpi
Print speed305 mm/s

Rolls and ribbon

Roll core diameter1.5" (37.5mm) - 3" (76 mm)
Ribbon (length, core, winding)450 Meters, width 4.5" (114.3 mm)

Platform

Memory512 MB; 128 MB Flash; SD card; up to 32 GB
DisplayColor LCD with buttons
Command languagesMost major printer languages: PGL/VGL/ZGL/TGL/IGL/STGL/DGL/IEGL/MGL/EGL; Most Major Printer Languages: PGL/VGL/ZGL/TGL/IGL/STGL/DGL/IEGL/MGL/EGL; emulation: PGL, VGL, ZGL

Connectivity and RFID

ConnectivityUSB, Ethernet, Wi-Fi, RS-232, Parallel
RFID✓

Options

Options (cutter, peeler, rewinder)cutter, peeler, rewinder

Dimensions

Dimensions (L × W × H)297.2 x 330.2 x 520.7 mm
Weight16.7 kg
